  A simple and inexpensive way to spruce up the appearance of an old set of gauges is by replacing the bezels and glass. Nisonger stocks a complete assortment of new replacement bezels, flat or convex glass, bezel gaskets, seals and dashboard o rings.





VOLTAGE STABILIZERS

Smiths electric oil pressure, water temperature and fuel level gauges require that a voltage stabilizer be wired into their circuit. All three gauges can be wired through one stabilizer.

Part Number Description
BR1307-00 Classic Instruments - Negative Earth
BR1310-00 Mini Voltage Stabilizer

OIL PRESSURE SWITCHES

Part Number Contacts Pressure Ground Description
PS3270-10-06B Close Falling Insulated 6psi M 12 x 1.75
PS3501-06 Close Falling Insulated 6psi 1/4 BSP
PS4201-06 Close Rising Insulated 6psi 1/4 BSP
PS4221-14 Close Rising Insulated 14psi 1/4 BSP
PS4221-17 Close Rising Insulated 17psi 1/4 BSP
PS4221-30 Close Rising Insulated 30psi 1/4 BSP
PS5305-07 Close Falling Earth 7psi M 10 x 10
PS5314-07A Close Falling Earth 7psi 3/8 BSF
PS5320-6-03 Close Falling Earth Triumph Spitfire
PS5320-6-07 Close Falling Earth 1/8 x 27 NPT 7psi
PS5327-07 Close Falling Earth 1/8 x 27 USA taper

OIL PRESSURE SENDERS, TRANSDUCERS

Part Number Description
PTR1000-6-10 100psi 1/8 x 27 NPT
PTR1001-10EC* 100psi 1/4 x 19
PTR1200-8N-16 160psi 1/8 x 27 NPT
PTR1801-06* 60psi 1/4 BSP
PTR1801-10* 100psi 1/4 BSP
PTR1812-06 60psi 1/2 UNF
PTR1810-1-10 100psi 1/8 NPT Cobra/Classic
PTR1812-10 100psi 1/2 UNF

*Specific Jaguar unit, but can be used for other applications.

Additional psi ranges and threads available.

OIL OR WATER TEMPERATURE SENDERS

Part Number Description
TT4806-00 5/8" x 18 UNF
TT6802-00 5/8" x 18 UNF
TT6807-00 M18 x 1.5 Insulated
TT6808-00 M14 x 1.5 Insulated
TT6811-01 Oil/Water 1/8" x NPT Cobra Classic

FUEL TANK SENDERS

All are 6 hole attachment and compatible with Smiths fuel gauges.

Part Number Description Ground
TB9006-KIT Top mount Earth/Frame
TB9011-KIT Top mount 6 hole flange Cobra/Classic Isolated/Terminal
TB9013-KIT Side mount 6 hole flange Cobra/Classic Isolated/Terminal
TFS9915-00R Mini Fuel Tank Sender, Blade Austin Mount

PROXIMITY SPEED SENSOR WITH REED SYSTEM

Part Number Description
EMP28-1 Magnetic 5/8 UNF Cobra
EMP34-KIT Speed Sensor M8 Cobra

OIL PRESSURE LINE

Original Smiths pressure line, screws to the back of oil pressure gauges.

Part Number Description
HF-22000-00-08 Smiths OEM Black Plastic Line - 6' long w/(2) 1/8" BSP Zinc Plated Steel Fittings

TUBE KIT FOR MECHANICAL PRESSURE GAUGES

Part Number Description
TK-6 Aftermarket Opaque Plastic Line - 6' long w/(2) 1/8" BSP Zinc Plated Steel Fittings

CABLE ANGLE DRIVES

Part Number Description
BG2401-05 MGB & MGC gearbox 1:1 ratio, staked washer in input end
BG2401-10 Jaguar V12 gearbox end, TH400 trans non-reversing 1:1 ratio driver gear for 3.5mm diam. flex
BG2402-02 Jaguar E-Type 3.8, gearbox end, 1.28:1 Ratio, Geared 14:11
BG2402-03 Morgan 4/4 Series III
BG2402-07 Multi Jaguar application 1:1 ratio, staked washer on input
BG2402-08 Jaguar E-type 4.2 and V12 gearbox end 14:11 ratio, staked washer on input
BG2410-30 Gray Market Range Rover NEMAG with plate reversed
BG2410-70spr Range Rover 1987 to mid 1989 speedo end, new retaining plate
BG2410-80 Reverser for 427 Cobra Counterclockwise Speedometer

REPLACEMENT GLASS & BEZELS, CABLES & LINES


Replacement Dashboard Gasket Sets

Replacement FLAT Glass, Bezels & Bezel Gaskets
for 52, 80, 100 and 125 mm Smiths and British Jaeger Instruments

Replacement CONVEX Glass, Bezels & Bezel Gaskets
for 52 and 125 mm Smiths & British Jaeger Instruments

Replacement Glass, Bezels & Bezel Gaskets
for SC and SSM series motorcycle speedometers
and RC and RSM series motorcycle tachometers

Custom Speedometer Cables
(427 Cobra Cable pictured)

Smiths Oil Pressure Lines
